DC/Frequency Converter - M6NXAP

7.5-mm wide ultra-slim design
Low profile allows the M6N module mounted in a 120-mm deep panel
Converts a DC input into a FM (frequency modulation) or PWM (pulse width modulated) signal
PC programmable
High-density mounting
Power and status indicator LEDs

M-System’s high performance signal conditioners are now packed in ultra-slim housings of only 5.9 mm (0.23 in) at the front face. Even though the power consumption of these modules is suppressed to the extreme low level, they can drive at the maximum of 550 Ω load with 4-20 mA DC output.

Each module is provided with a green power indicator LED to help you diagnose its status. In order to save you from individual power input wiring, the Installation Base holding eight modules can be expanded up to six bases for the maximum of 48 modules supported by a common power supply.
